Overall Dimensions

Boom Length
4000mm13' 1"
Stick (Arm) Length
2000mm6' 7"
Transport Length
6560mm21' 6"
Transport Width
2260mm7' 5"
Transport Height
3200mm10' 6"
Upper Structure Width
2160mm7' 1"
Cab Height
Blade Height
Track Width (standard shoe)
Track Gauge
1810mm5' 11"
Ground Clearance (minimum)
Tail Swing Radius
1885mm6' 2"
Track Length on Ground
2340mm7' 8"
Track Length
2980mm9' 9"

Technical Specifications

Operating Weight
9180 kg20,238 lb
Ground Pressure
38.6 kPa5.6 psi
EngineYanmar 4TN98CT-VSY
3.3 L201.4 in3
Gross Power
53.7 kW72 HP
HydraulicsLoad Sensing with Pilot Control
Main Hydraulic PumpAxial Piston - Variable Displacement
Operating Flow (maximum)
199.5 L/min52.7 gal/min
Operating Pressure (maximum)
26.3 MPa3814 psi
Power Boost Pressure (maximum)
Travel MotorAxial Piston with Park Brake
Travel Pressure (maximum)
26.3 MPa3814 psi
Travel Speeds (maximum)
2.9 / 5.0 km/hr1.8 / 3.1 mph
Travel Effort (maximum)
83.0 kN18,659 lbf
Grade Capability35º
Swing MotorAxial Piston with Swing Brake
Swing Pressure (maximum)
21.5 MPa3118 psi
Swing Speed (maximum)11 rpm
Undercarriage (standard)Steel Track
Track Shoe Width (standard)
450 mm18"
Track Rollers (per side)5
Carrier Rollers (per side)1

Working Range

Boom Length
4000 mm13' 1"
Stick (Arm) Length
2000 mm6' 7"
Maximum Digging Height
7260 mm23' 10"
Maximum Dumping Height
5210 mm17' 1"
Maximum Digging Depth
4330 mm14' 2"
Maximum Vertical Wall Digging Depth
3080 mm10' 1"
Maximum Reach at Ground Level
6660 mm21' 10"
Minimum Swing Radius
1990 mm6' 6"
