Overall Dimensions

Boom Length
3000mm9' 10"
Stick (Arm) Length
1700mm5' 7"
Transport Length
6015mm19' 9"
Transport Width
2005mm6' 7"
Transport Height
2645mm8' 8"
Upper Structure Width
1860mm6' 1"
Cab Height
Blade Height
Track Width (standard shoe)
Track Gauge
1600mm5' 3"
Ground Clearance (minimum)
Tail Swing Radius
1640mm5' 5"
Track Length on Ground
2045mm6' 9"
Track Length
2545mm8' 4"

Technical Specifications

Operating Weight
6100 kg13,448 lb
Ground Pressure
34.6 kPa5.0 psi
EngineYanmar 4TNV98C-WSY
3.3 L202.5 in3
Gross Power
42.4 kW56.9 HP
HydraulicsLoad Sensing with Pilot Control
Main Hydraulic PumpAxial Piston - Variable Displacement
Operating Flow (maximum)
142.7 L/min37.7 gal/min
Operating Pressure (maximum)
24.5 MPa3553 psi
Power Boost Pressure (maximum)
Travel MotorAxial Piston with Park Brake
Travel Pressure (maximum)
24.5 MPa3553 psi
Travel Speeds (maximum)
2.4 / 3.7 km/hr1.5 / 2.3 mph
Travel Effort (maximum)
47.2 kN10,611 lbf
Grade Capability35ยบ
Swing MotorAxial Piston with Swing Brake
Swing Pressure (maximum)
19.1 MPa2770 psi
Swing Speed (maximum)9.6 rpm
Undercarriage (standard)Belted Rubber Track
Track Shoe Width (standard)
400 mm16"
Track Rollers (per side)5
Carrier Rollers (per side)1

Working Range

Boom Length
3000 mm9' 10"
Stick (Arm) Length
1700 mm5' 7"
Maximum Digging Height
5790 mm19' 0"
Maximum Dumping Height
4060 mm13' 4"
Maximum Digging Depth
3950 mm13' 0"
Maximum Vertical Wall Digging Depth
3180 mm10' 5"
Maximum Reach at Ground Level
6320 mm20' 9"
Minimum Swing Radius
2555 mm8' 5"
